G10 Epoxy glass fiber Laminate tube

G10 Epoxy glass fiber Laminate tube

Product number:KXT 100GS

Quick Overview: G10 epoxy fiber glass tube is made from electrical glass cloth that impregnated with epoxy resin under pressure and heat, with Mechanical and electrical application, good moisture resistance.3840, 3841 (China standard) is in accordance with G10 (NEMA standard)

Send Inquiry

PDF DownLoad

Product Description

G10 epoxy fiber glass tube is made from electrical glass cloth that impregnated with epoxy resin under pressure and heat, with Mechanical

and electrical application, good moisture resistance. In accordance with G10 (NEMA standard)



Epoxy glass fiber wound tube with high mechanical strength and electrical properties, thermal-resistant and wet resistant. Made from electrical

E-glass cloth that has been impregnated with epoxy resin under high pressure and heat.



Specification:

Diameter range: From 8mm to 800mm

Wall thickness : 0.5mm-more

Max length: 12 m



G10 Material Properties

General data

Temperature class

axis electrical strength in oil at 90 oC

Axial electrical strength in oil at 90 oC

Insulation resistance after 24 hrs in water

Water absortion

Cohesion bettwen layers

Standard density

Item name

Glass with epoxy resin tube

130 oC

8 KV

45 KV

103

1.5

350

1.8

G10

Fine glass with epoxy tube

155 oC

9 KV

70 KV

105

0.4

400

1.7

G11

Glass with epoxy resin tube

155 oC

9 KV

75 KV

104

0.3

350

1.8

G11

Glassfiber with silicon resin

220 oC

8 KV

45 KV

104

0.2

160

1.65

G7

Glass with polyester resin

130 oC

6 KV

35 KV

103

0.6

230

1.7

Glassfiber with Silicon resin

220 oC

8 KV

45 KV

104

0.2

160

1.65

G7

Glass with melamine resin

155 oC

6 KV

30 KV

105

2

220

1.8

G5
